ANSOL Transmission3D Rev322

2017 年 5 月 29 日 月曜日

前回のRev320から未だひと月程ですが、以下の内容が修正されたRev322がリリースされました。
Rev322は弊社サイトからダウンロードできます。
本日からディレクトリ構成を少し変更しています。

install/プログラム名/インストーラ&ユーザマニュアル等
・Transmission3D のディレクトリ名は、TM3D になりました。
・かなり古いインストールファイルは削除しました。

以下リリースノートです。

Rev 322 – 2017-05-18 16:18:14 -0400 (Thu, 18 May 2017)
==========
1)Added option to allow user defined reference frames for bearings.
  Previously, the user could only specify the Z axis of the bearing,
  and the X and Y axes were automatically calculated. Now the user
  can use the SPECIFY_X_AXIS checkbox to also specify the X axis
  orientation. The Y axis is therefore also determined.

2)Added a small reference frame in the top right corner of the 3D
  windows in iSys to indicate the orientation of the reference frame.
  The X, Y, Z axes are identified by the their color.

3)Added buttons LOAD_SB_SUMMARY, LOAD_IB_SUMMARY and LOAD_OB_SUMMARY in the
  HYPOID|SUMMARYFILE menu, to read the Gleason text summary. If the .spa file
  is not available, but the machine summary is available, then
  this button can be used to load the machine settings and cutter
  geometry. The LOAD_SB_SUMMARY loads both sides. The other two
  buttons will load only a single side.

4)Added torque harmonics feature. If the rotor is of TYPE+OUTPUT,
  then a ENABLE_TORQUEHARMONICS checbox is visible. Turning
  on this option will allow you to superimpose NTORQUEHARMICS
  harmonics. Each harmonic in the ROTOR|HARMONIC menu is specified
  by an AMLPITUDE, ORDER and PHASE. AMPLITUDE is the zero to peak
  variation. ORDER specified the harmonic’s frequency as an
  order (multiple) of the rotor’s rotation frequency. A PHASE
  of zero will create maximum torque at T=0.

5)Added a way to have higher resolution at specific
  teeth for conformal sun-ring contact. This will be
  useful in modeling splines. Use the ENABLE_MULTIPLE_CONTACT_GRID
  checkbox in the PAIRS menu to access this feature.

6)Added a way to have higher resolution at a specific bearing roller.
  Use the ENABLE_MULTIPLE_CONTACT_GRID checkbox in the
  bearing’s CONTACT_GRID menu to access this feature

7)Peak memory is now reported in MB instead of GB.

8)Increased number of load sensors, number of FE Probes and
  number of surface gages to 400

9)Added option to parallelize geometric search.

10)When creating a report file from iSys, it did not create
  the file correctly if the path name has a space in it

11)Added flank TWIST modification for involute gears

12)Added new ADD_BASE_SHAFT button in Guide, in the HYPOID|COMMON menu
   of face-milled and Face-hobbed gears and pinions, to crteate a
   shaft that correctly interfaces with a hypoid.

13)Added USE_SPRD_BLD_THICKNESS checkbox in the COMMON menu
   for face-milled pinion and gear. When this option is checked,
   the machine settings for both sides must be the same, otherwise
   and error message will be emitted. If the machine settings are
   the same for both sides, then it will assume that both sides of
   the tooth slot are cut simultaneously, so it does not need to
   ask the user for the tooth thickness.

14)Added a coefficient of friction to customized menu for
   the SHAFT-SHAFT contact PAIR in iSys. Previously it was only visible
   in the native menu and in Guide.

15)Added a PARALLELIZE_SEARCH checkbox in the SETUP menu. It is
   turned OFF by default. Turning it ON enables an experimental
   feature, which parallelizes the geometric search part of the
   analysis. It is not 100% stable, so it is only meant for
   experimentation.

16)Bug Fix: Models with both roller bearing and a shaft segment with non-zero
   rigid constraint failed to load in calyx.

17)Bug fix: On Linux, the memory footprint reported did
   not include virtual memory.
 注)仮想メモリサイズを含んだ全メモリサイズが表示されない現象が、Linux版では
   修正されました。Windows版は、実メモリサイズ表示のままです。

18)Bug fix: When using adaptive grid sizing, calyx could crash if the
   STARTANAL command is used without a preceding GENERATE command.

19)Bug Fix: Changes in Rev 318 triggered generate error when
   RING-PINION pair is defined in the CARRIER menu.

20)Bug Fix: Fixed a problem with geometric search for a hypoid gear pair.

2017年 ゴールデンウイーク

2017 年 5 月 9 日 火曜日

4/29 – 5/7 今年前半は、実家の都合で東北地方観光地巡り、後半は娘の希望で韓国ソウルに行った。

4/29 弘前公園 桜祭り

桜満開で弘前公園に来るのは、45年振り??  天守閣は修復のため移動中

行った証拠

花筏と言うらしい

4/30 八戸 蕪島

前回来たのは、昨年8月。今年は繁殖シーズンらしく数万羽のウミネコ(天然記念物)

いつもの様に、大学の後輩が迎えてくれた。みろく横丁入口で記念撮影

5/1 平泉 中尊寺

目に良い

5/2 仙台 松島

ここでは、ウミネコへの餌やりは禁止だ。

5/4-7 ソウル

ソウルは少し心配だったので、娘に確認したところ「何のこと?」、、、、ニュースなんて見ていないのだ。
運よくUAのマイレージチケットが取れたので、これは行くしかない。

行った証拠、隣は次女

ミョンドン  大勢の観光客

南大門、、、だったと思う

北村

漢口遊覧船

どこか忘れてが、屋台

暑さに耐えきれず倒れてしまった冬季五輪マスコット発見。

何年振りかでナンタも鑑賞

結局何の問題もなく、市内は多くの観光客で溢れていた。
